PSA Oxygen Generator
Overview
PSA oxygen generators produce high-purity oxygen gas from compressed air using pressure swing adsorption technology, ideal for continuous industrial gas supply.
Principle
Atmospheric air is compressed and filtered to remove dust, oil, and moisture.
Compressed air passes through adsorption vessels filled with zeolite molecular sieves.
Nitrogen is selectively adsorbed, allowing oxygen to pass through as the product gas.
Adsorbent beds are regenerated by reducing pressure in a cyclic process.
Oxygen is collected, stored, and delivered for industrial use.
Types
Skid-Mounted PSA Oxygen Generators
Containerized Oxygen Plants
High-Capacity Industrial Oxygen Systems
Applications
Metal cutting, welding, and fabrication
Steel and non-ferrous metal production
Glass manufacturing and refining processes
Chemical and petrochemical industries
Wastewater treatment and aeration
Specifications
Oxygen flow rate: 1–500 Nm³/h
Purity: 90% – 95%
Working pressure: 4–10 bar
Operating temperature: 5°C – 45°C
Power consumption: 0.8–1.2 kWh/Nm³
Features
Fully automatic PLC-controlled system
Energy-efficient and cost-saving operation
Compact skid-mounted or containerized design
Low maintenance with long adsorbent life
Continuous and reliable oxygen supply
Certifications
ISO 9001 (Quality Management)
ISO 14001 (Environmental Management)
ASME Certification
CE Certification
ISO 13485 (for medical-grade systems, optional)
Benefits
Eliminates dependency on oxygen cylinders
Lower operating and logistics costs
On-site oxygen generation for uninterrupted supply
Environment-friendly solution
Reliable and consistent purity levels
Challenges
Requires continuous compressed air supply
Air pre-treatment system maintenance required
Limited purity compared to cryogenic systems
Initial setup cost
